TP0050CalibratorsFlukeVersion 1.0

5820A Oscilloscope Calibrator

Automated performance verification procedure for the 5820A Oscilloscope Calibrator. Gilium controls the unit under test and the reference standards, records each reading against its tolerance and produces the report.

Tests
33
Models covered
1
Adjustments
Yes
5820A Oscilloscope Calibrator product photo

Tests performed

Run all tests or select a subset. Each test has its own connection diagram.

  1. DC Voltage - 1MΩ
  2. AC Voltage - 1MΩ
  3. Tunnel Diode Pulser Amplitude
  4. Wavegen Amplitude - 1MΩ
  5. DC Voltage - 50Ω
  6. AC Voltage - 50Ω
  7. Edge Mode - Amplitude
  8. Wavegen Amplitude - 50Ω
  9. LEVSINE Amplitude (@50 kHz)
  10. DC Current
  11. AC Current
  12. Impedance Measurement
  13. AC Voltage Mode - Frequency Accuracy
  14. Edge Mode - Frequency Accuracy
  15. Pulse Period
  16. Time Marker
  17. LEVSINE Frequency Accuracy
  18. Edge Mode Risetime
  19. Edge Aberrations
  20. Pulse Width
  21. Pulse Skew
  22. LEVSINE Harmonics (<600 MHz)
  23. LEVSINE Harmonics (>600 MHz)
  24. CH1 LEVSINE Flatness (<600 MHz)
  25. CH1 LEVSINE Flatness (>600 MHz)
  26. CH2 LEVSINE Flatness (<600 MHz)
  27. CH2 LEVSINE Flatness (>600 MHz)
  28. CH3 LEVSINE Flatness (<600 MHz)
  29. CH3 LEVSINE Flatness (>600 MHz)
  30. CH4 LEVSINE Flatness (<600 MHz)
  31. CH4 LEVSINE Flatness (>600 MHz)
  32. CH5 LEVSINE Flatness (<600 MHz)
  33. CH5 LEVSINE Flatness (>600 MHz)

This procedure includes an Adjustments session.
