TP0901BWaveguide & AttenuatorsVariousVersion 1.0

Rotary Vane Attenuator w/8510

Automated performance verification procedure for the Rotary Vane Attenuator w/8510. Gilium controls the unit under test and the reference standards, records each reading against its tolerance and produces the report.

Tests
9
Models covered
2
Adjustments
No
Rotary Vane Attenuator w/8510 product photo

Tests performed

Run all tests or select a subset. Each test has its own connection diagram.

  1. VNA Initialization
  2. 0 dB Attenuation
  3. 3 dB Attenuation
  4. 6 dB Attenuation
  5. 10 dB Attenuation
  6. 20 dB Attenuation
  7. 30 dB Attenuation
  8. 40 dB Attenuation
  9. 50 dB Attenuation
