TP0316Network & Noise Figure AnalyzersCopper MountainVersion 1.0

C4220 Network Analyzer

Automated performance verification procedure for the C4220 Network Analyzer. Gilium controls the unit under test and the reference standards, records each reading against its tolerance and produces the report.

Tests
15
Models covered
-
Adjustments
No
C4220 Network Analyzer product photo

Tests performed

Run all tests or select a subset. Each test has its own connection diagram.

  1. Frequency Accuracy
  2. Output Power, Port1
  3. Output Power, Port2
  4. Trace Noise, S11
  5. Trace Noise, S22
  6. Trace Noise, S21
  7. Trace Noise, S12
  8. Noise Floor, S21
  9. Noise Floor, S12
  10. Initialize VNA for Uncor. Param.
  11. Uncorrected Parameters
  12. Initialize VNA for Artifact Verification
  13. 20dB Artifact Verification
  14. 40dB Artifact Verification
  15. Mismatch Artifact Verification
