AG1001ANI DAQ & PXI ModulesNIVersion 1.0

NI-9226 RTD Input Module

Automated performance verification procedure for the NI-9226 RTD Input Module. Gilium controls the unit under test and the reference standards, records each reading against its tolerance and produces the report.

Tests
8
Models covered
1
Adjustments
Yes
NI-9226 RTD Input Module product photo

Tests performed

Run all tests or select a subset. Each test has its own connection diagram.

  1. CH1 Resistance
  2. CH2 Resistance
  3. CH3 Resistance
  4. CH4 Resistance
  5. CH5 Resistance
  6. CH6 Resistance
  7. CH7 Resistance
  8. CH8 Resistance

This procedure includes an Adjustments session.
